LION 1000 - Cayman 88 - Tigres - Falkon
4.1 Electrical cable section
It is essential that the anchor windlass be wired with cables of sufcient section as suggested in the table.
4.2 Contractor (Control Box)
Place it in a dry place near the capstan.
4.3 Circuit breakers
The circuit breakers recommended by Lofrans have an intervention curve and not a simple plate value. The switches selected for each
model guarantee the correct operation of the system.
4.4 Remote control electric panel board
The remote control electric panel board must be mounted in a comfortable position (such as the deck, the rudder or the cockpit), so that
the operator can see the capstan during the manoeuvre. Mount and seal the electric panel board so that the terminals remain in a dry
place.
4.5 Protection of electrical components
The installer is responsible to properly protect the motor and the electrical components (such as the control box) from direct water
contact. Water damage to the electrical components due to water ingress will void the warranty. Also the installer is responsible to ground
the windlass unit.
4 ELECTRICAL SYSTEM
Model
Motor
Power (W)
Voltage (V)
Contactor
(A)
Cable sizing according length of cable
(positive + negative)
15-25 m 50-75 ft > 25 m > 75 ft
Atlas/Cayman 88
/Lion 1000
600/700/700 12 70 25 mm
2
3 AWG - -
Cayman 88 700 24 35 16 mm
2
4 AWG - -
Cayman 88 1000 12 100 35 mm
2
2 AWG 50 mm
2
2 AWG
Cayman 88 1000 24 70 25 mm
2
3 AWG 35 mm
2
3 AWG
Cayman 88 1300 48 35 6 mm
2
10 AWG 10 mm
2
8 AWG
Tigres 1500 12 100 50 mm
2
2 AWG 75 mm
2
000 AWG
Tigres 1500 24 70 35 mm
2
3 AWG 50 mm
2
2 AWG
Tigres 1500 48 35 16 mm
2
4 AWG 25 mm
2
3 AWG
Falkon 1700 12 125 50 mm
2
2 AWG 75 mm
2
000 AWG
Falkon 1700 24 70 35 mm
2
3 AWG 50 mm
2
2 AWG
Falkon 2000 24 100 50 mm
2
2 AWG 75 mm
2
000 AWG
Falkon 2200 48 70 10 mm
2
8 AWG 16 mm
2
6 AWG
