www.lofrans.com
UK
3.5 Prevention from electrolysis
Make sure that the anchor and chain are insulated from the hull, including chain locker and
xing systems.
For motors with 2 terminals (LION 1000, CAYMAN with 700W motor), the installer must ground
the windlass by connecting a bonding wire to the cathodic protection on board.
For aluminum boats, all windlasses must be insulated from the deck through a non-conductive
gasket (not supplied).
3.6 Deck installation
1. Place carefully the drilling template on the deck, by ensuring the correct alignment with the bow.
2. Mark and drill as indicated in the gure. Let the edges of the holes sharp, while the edge side of the holes of the chain
towards the bow must be smoothed for an angle of 45° degree.
3. Place carefully the upper part of the anchor windlass on the deck.
4. Carefully place the chain stripper pipe so that the chain stripper is aligned and away 4-5 mm from the gipsy throat.
5. Connect the wires from the battery to the electrical engine by passing them out through the openings in the gearbox body.
Note:
It is recommended to seal the base of the anchor windlass to the deck by means of silicone glue.
1
Without these precautions, the electrolysis phenomenon will lead to a rapid corrosion of the anchor windlass.
32
4
5
