www.lofrans.com
5
5 SETTING AND OPERATION
- Before switching on the power to the control, check that all the electrical connections are correct.
- Push UP or DOWN command to use windlass or any other equipment.
- Release the button to stop.
DON’T PUSH THE BUTTONS SIMULTANEOUSLY!
4.3 Connecting the control panel to the socket
Connecting
After installing the socket as described above, proceed as follows:
• Rotate the ring-nut of the protective cover anticlockwise until screw off and remove.
• Insert the instrument plug into the relevant socket, taking care that the position of insertion is correct.
• Turn the plug locking ring-nut clockwise until fully closed.
Disconnecting
• Turn the plug locking ring-nut anticlockwise until fully open and remove.
• Cover the socket with the cover provided and turn the ring-nut clockwise until it is fully tightened.
4.4 Wiring
WARNING!
Always ensure that the socket is closed with the cover provided when the instrument is disconnected.
For the connection of the electrical wires refer to the wire colorings as in Fig.1
UKUK
