4. Adjust four of the fixing hooks (see arrows in image on the right) on the back of the
panel to determine where the ceiling kit will be mounted.
5. Remove all parts of the ceiling kit from the plastic bag (4x cord, 4x ceiling
part, 4x screw, & 4x plug).
6. If connected, unscrew the bolt (D) from the ceiling part (C).
7. Hold the bolt (D) between your index and middle finger,
press the button (E) with your thumb and hold to adjust the
length of the cords. You can adjust the length by pulling or
pushing the cord through the bolt (D) while holding the button
(E).
8. Make sure all four cords are the same length so that the panel will hang
completely level.
9. Attach the four cords to the back of the heat panel, by screwing the other side of
the cord (F) into the four fixing hooks (see arrows) that you adjusted in step 4.
On the ceiling:
1. Based on the position of the adjusted fixing hooks on the back of the panel,
mark four spots on the ceiling where you want to drill holes. Use a tape
measure.
2. Make a M6 size hole in the ceiling and install the plug (A).
3. Repeat this for the other three marked spots on the ceiling.
4. Screw the ceiling parts (C) into the plugs with the supplied screw (B), until it is
completely fastened.
5. Once all ceiling parts (C) have been fastened, bring the heat panel closer, so
you can screw all bolts (D) into the ceiling parts (C). Keep holding the heat
panel to prevent it from falling.
6. Once all bolts (D) and ceiling parts (C) have been connected tightly, slowly
lower the heat panel and check if the ceiling kit is connected correctly and will
hold the weight of the heat panel.
7. If you are sure that everything has been installed correctly and the ceiling kit
can hold the weight of the panel, you can gently let go of the panel. The panel
has now been successfully mounted to your ceiling and can be plugged into the
wall socket.
A
B
C
D
E
F
