4. Adjust four of the fixing hooks on the back of the panel (see arrows in image on the
right) to determine the positions where you want to hang the panel to the wall.
5. Based on the position of the adjusted fixing hooks on the back of the panel,
mark four spots on the wall where you want to drill holes. You can
measure them out using a measuring tape.
6. Drill four holes with a diameter of M6 and a depth of 40mm
in the wall. Make sure that the two adjacent holes are level.
7. Then insert the supplied plastic anchors/plugs into the drilled
holes.
8. Use a screwdriver to tighten the supplied screws into the plastic
anchors/plugs; leave the head of the screw protruding from the hole by
6mm.
9. Make sure the fixing hooks are tightened and hang the fixing hooks on the
protruding screws. Feel if the panel is firm and stable once it has been hung.
Floor Standing
If you want to place the heat panel on the floor, you should
always use the separately available Livn standing feet.
Placing the appliance on the floor without these standing
feet is dangerous and poses a high risk of fire.
1. Make sure the heat panel is not plugged into the wall
socket.
2. Place the standing feet on the surface where you want
to place the heat panel.
3. Lift the heat panel and place it on the standing feet.
4. Make sure that the heat panel, including the standing
feet, is always on a firm, level, and horizontal surface.
Please note: long-pile carpets are unsuitable.
Ceiling Mounting
If you want to attach the heat panel to your ceiling, you should always use the separately
available Livn ceiling kit. Note: Before drilling, make sure that there are no wires or pipes in the
ceiling in order to prevent electric shock or damage to plumbing.
Attaching the ceiling kit to the heat panel:
1. Make sure the heat panel is not plugged into the wall socket.
2. Before mounting, determine where you want to attach the panel to the ceiling. The ceiling
should be firm, level and made of heat-resistant material.
3. Place the heat panel on a soft surface with the back facing upwards.
