22 GB/IE
Assembly
Please ensure that the product is
only assembled / disassembled by
a competent person.
Note: Product assembly requires
at least 2 persons. We recommend
assembly with 4 persons.
Assemble pavillion
(Fig. A to I)
Step 1
Remove the article from the
storage bag.
Step 2
Slowly and evenly extend the
product at the opposite corners
(Fig. A and B).
Step 3
Slide the corner joints
2
for each
corner as far up until the lock-
ing pin on the corner poles
15
locks in (Fig. C).
Note: Great resistance indicates
the product is not yet extended
far enough.
Attention! Pinching hazard
at the corner joint
2
!
Step 4
Extend the telescoping feet
10
in the corner poles
15
. To do so,
place one foot onto the base
plate
4
of the feet and slide
the upper part of the corner
pole
15
up until you hear the
telescoping foot
10
lock in
(Fig. D).
Note: You may choose from
3 height settings.
Step 5
Tighten the corner tarps
6
by
securing the factory installed
hooks
7
in the designated
opening on the telescoping
foot
10
(Fig. E).
There are 3 openings to choose
from:
When the telescoping foot
10
is
locked into the lowest position,
also secure the hook
7
in the
lowest position.
When securing the telescoping
foot
10
in the middle or top po-
sition, also select the respective
middle or top opening.
Step 6
Anchor each telescoping foot
10
using the included tent pegs
3
using the openings in the base
plate
4
(Fig. F).
