11
Congratulations!
You have chosen to purchase a high-quality
product. Familiarise yourself with the product
before using it for the first time.
Read the following assembly
instructions and the safety
information carefully.
Use the product only as described and only
for the given areas of application. Store these
assembly instructions carefully. When passing
the product on to third parties, please also hand
over all accompanying documents.
Package contents (Fig. A)
1 x backrest (1)
1 x seat (2)
1 x base (3)
1 x connecting part with lever (4)
1 x pneumatic spring (5)
1 x pneumatic spring cover, 3-part (6)
5 x castor (7)
4 x screw, short (8)
4 x washer (9)
4 x screw, long (10)
1 x hex key (11)
1 x assembly instructions
Technical data
Suitable for children aged between
4 and 11 years
Seat height: approx. 41–51cm
Size class 4 according to DIN EN 1729-1:2016
Castors suitable for soft floors
60
Maximum load: 60kg
Date of manufacture (month/year):
03/2022
Intended use
The product is not intended for commercial use.
This product has been developed for private
indoor use.
Safety information
Life-threatening hazard!
• Never leave children unattended with the
packaging materials. There is a risk of suffo-
cation.
Risk of injury!
• Ensure the product is properly stabilised
before using it.
• Place the product on a level surface.
• The product may only be used under adult
supervision and must not be used as a toy.
• The product is not a toy or climbing appara-
tus! Ensure that persons, especially children,
do not pull themselves up on the product or
lean against it. The product can tip over.
• Check the product for damage or wear
before each use. Only use the product if it is in
perfect condition!
• Ensure that the product has been assembled
properly and in accordance with these instruc-
tions for use. Improper assembly can lead to
injuries and impair the product’s safety and
functionality.
• The pneumatic spring may only be replaced
or repaired by trained expert personnel.
• Never stand on the product.
Assembly
Note: enquire at a specialist shop about castors
that are suitable for your floor.
1. Turn over the base (3) and push the cas-
tors (8) into the openings provided (3a), up to
the notch (Fig. B).
2. Stand the base on the castors.
3. Next insert the pneumatic spring (5) into the
base and then place the pneumatic spring
cover (6) over the pneumatic spring (Fig. C).
4. Screw the connecting part with lever (4) onto
the underside of the seat (2) (Fig. D).
Note: pay attention to the correct alignment of
the seat.
GB/IE
