20 GB/IE
Intended use
The product is intended for automatic lighting in outdoor areas only. This
product is solely intended for private use and not for commerical use.
Parts description
1
Spotlight
2
Locking screw
(mounting bracket)
3
Spring washer
4
Tooth lock washer
5
Mounting screw
6
Wall plug
7
Mounting bracket
8
Motion detector
9
Neutral conductor (blue)
10
Protective conductor
(yellow-green)
11
Outer conductor (brown)
12
Rotary control LUX
(light sensitivity)
13
Rotary control TIME
(switched on duration)
14
Terminal block
(not included in the delivery)
Technical data
Operating voltage: 230 V∼ 50 Hz, 10 W
LEDs: 15 x LED (LEDs are non-replaceable.)
Dimming switch: adjustable from 10 lx–20,000 lx
Light on time: adjustable between approx. 10 s–7 min
Protection class: I
Protection class: IP54 (dust protected and splash-proof)
Dimensions (H x W x D): approx. 16.4 x 11.4 x 7.1 cm
Projected area: max. 160 cm²
Mounting height: approx. 2.5 m
