14 GB/IE
5. Mark the drilling ranges using the screw holes
in the base plate
3
.
6. Using a 6 mm masonry drill, drill an approx.
30 mm deep hole into the marked positions.
7. Insert a dowel
2
into each drilled hole.
8. Guide the connection cable (external)
9
through the rubber tube
1
and the base plate
3
hole and place the base plate
3
on the
ceiling, so that the screw holes are congruent
with the drill holes.
9. Fix the base plate
3
to the ceiling using the
screws
5
.
10. Release the screws and open the cover cap on
the LED driver
4
.
11. Use a screwdriver to fasten the connection cable
(external)
9
to terminal block
7
. Make sure
you follow the correct polarity which marked on
the LED driver
4
. Ensure the rubber tube
1
should completely cover the connection cable
(external)
9
.
12. Screw the cover cap to the LED driver
4
again
using the screw.
13. Attach the light cover
6
to the base plate
3
by rotating the light cover
6
clockwise.
14. Screw the fuse on and / or switch the circuit
breaker on again.
Model HG05024B (Square shape)
1. Unscrew the fuse and / or switch off the circuit
breaker and secure the circuit from accidental
starting.
2. Using a metal test instrument ensure the there
are no cables or pipes in the drilling ranges.
3. If necessary, choose nother place to install the
light.
4. Remove the light cover
6
from the base plate
3
by rotating the locking lever
8
open.
5. Mark the drilling ranges using the screw holes
in the base plate
3
.
6. Using a 6 mm masonry drill, drill an approx.
30 mm deep hole into the marked positions.
7. Insert the dowel
2
into each drill hole.
8. Guide the connection cable (external)
9
through the rubber tube
1
and the base plate
3
hole and place the base plate
3
on the
ceiling, so that the screw holes are congruent
with the drill holes.
9. Screw the base plate
3
to the ceiling using
the screws
5
.
10. Release the screws and open the cover cap on
the LED driver
4
.
11. Use a screwdriver to fasten the connection cable
(external)
9
to terminal block
7
. Make sure
you follow the correct polarity which marked on
the LED driver
4
. Ensure the rubber tube
1
should completely cover the connection cable
(external)
9
.
12. Screw the cover cap to the LED driver
4
again
using the screw.
13. Attach the light cover
6
to the base plate
3
by closing the locking lever
8
.
14. Screw the fuse on and / or switch the circuit
breaker on again.
Switching the product on / off
Use the wall switch to switch the product on
and off.
Maintenance and cleaning
Allow the product to cool down completely.
Do not use solvents, benzene or similar sub-
stances. They could damage the product.
DANGER TO LIFE BY ELEC-
TRIC SHOCK! Before carrying out any tasks
on the product, switch off the electrical circuit at
the circuit breaker box or remove the fuse from
the fuse box.
RISK OF ELECTRIC SHOCK!
For electrical safety, never clean the product with
water or other liquids, or immerse it in water.
Only use a dry, lint-free cloth for cleaning.
Never aim the LED beam at reflective surfaces,
people or animals. Failure to observe this advice
may result in eye irritation and / or blindness in
humans and animals. Even a weak LED light
beam can cause eye damage.
After finished the maintenance and cleaning,
screw the fuse on and / or switch the circuit
breaker on again.
