17 GB/IE
Safety notices / Preparation / Prior to installation / Installation Installation / Start-up
Secure the wall bracket
3
to the wall using the
self-tapping screws.
Note: If the mounting position is higher than
3 m, use an additional self-tapping screw and
washer (not included).
After mounting, verify the wall bracket
3
is
securely fitted.
Open the cable terminal box
2
by loosening
the four screws
1
.
Now insert the flexible supply cable (Type
H05RN-F 3G 1.0 mm
2
) through the cable
gland
16
and into the cable terminal box
2
.
Connect the cable
11
,
12
,
13
with the terminals
L,
and N by tightening the screws (see Fig. B).
Secure the flexible supply cable, type H05RN-
F 3G 1.0 mm
2
in the cable holder by tightening
the screws.
Screw the cable gland
16
until it is watertight.
Close the cable terminal box
2
using the four
screws
1
until it is watertight.
Replace the fuse or switch on the circuit breaker
in the circuit breaker box.
The light is now ready for operation.
Notice:
If the lighting angle is not ideal, switch the light off
and allow to cool down for 15 minutes. Loosen the
adjusting screws
4
with a screwdriver and read-
just the lighting angle. Then tighten the adjusting
screws
4
.
Start-up
Note: The LED light has a motion detector
9
which responds to temperature changes.
The motion detector
9
works best in ambient tem-
peratures below 20 °. A moving object with a tem-
perature near the ambient temperature is difficult to
detect.
Note: The control dials are located below the
motion detector
9
(Fig. A).
Note: The maximum range of the motion detector
9
is approx. 12 m, the detection radius is approx. 180 °.
Note: The horizontal directional angle of the motion
detector
9
is approx. 130 °. The vertical direc-
tional angle of the motion detector is approx. 90°.
Do not adjust the motion detector
9
with
force. The safety stops could break.
Aligning the motion detector
Note: The detection area must be well within range
of the infrared beams from the motion detector
9
.
The view of the detection area must not be obstructed
by objects such as plants etc. Infrared beams cannot
pass through solid objects.
Note: The detection area should run transversely
to the direction of passage and be kept as small as
possible. A large detection area increases the risk
of the light being switched on for irrelevant reasons.
1. First align the motion detector
9
horizontally.
2. Then loosen the locking screw (motion detector)
5
by turning it counter-clockwise.
3. Now align the motion detector
9
vertically and
tighten the locking screw (motion detector)
5
clockwise.
4. Test your settings by walking slowly into the de-
t
ection area. Repeat steps 1 to 3 until you ach
ieve
the desired result.
Automatic operation
Adjusting the sensor sensitivity (SENS):
Adjust the sensor sensitivity to your preferences
using the SENS rotary control
6
.
Turn clockwise to increase the sensor sensitivity.
Turn counter-clockwise to decrease the sensor
sensitivity.
Note: The further right the rotary control is turned,
the more sensitive the motion detector will be, i.e. it
will already respond to minor temperature changes
within the detection range. If the sensitivity is set too
high, even small animals or movement from leaves
(from trees or shrubs) may already trigger the mo
tion
sensor, inadvertently activating the light.
Adjusting the on duration (TIME):
Set the desired switch-on time of the lamp
(5 s ± 5 s - 10 min ± 2 min) using the TIME
rotary control
7
.
Turn clockwise to increase the on time. Turn
counter-clockwise to decrease the on time.
