17 GB/IE
Safety / Preparation / Prior to installation / Start-up Start-up / Maintenance and Cleaning
Place one silicone ring
8
over each of the in-
stalled spacers
7
.
Place the glass plate
9
onto the spacers
7
.
Be sure the trim faces outward.
Secure the glass plate
9
by installing the silic
one
rings
10
and securing it with the box nuts
11
.
Be sure they are seated correctly.
Use the slotted holes on the mounting bracket
2
to mark the bores.
Now drill the fixing holes (approx. 6 mm, depth
approx. 30 mm). Be careful not to damage the
supply line.
Feed the power cord (external)
13
through the
cable guides
12
.
Insert the plugs
1
into the bores.
Fasten the mounting bracket
2
with the pro-
vided screws
4
.
Now connect the connection cable of the light
with the connection cable (external)
13
using
the terminal block
14
.
Note: be sure to correctly connect the individ-
ual leads on the mains cable (external)
13
: live
wire, black or brown = symbol L, neutral wire,
blue = symbol N, earth wire, green-yellow =
symbol
.
Now use the screws
3
to connect the light to
the mounting bracket
2
.
Replace the fuse or switch on the circuit breaker
in the fuse box (position I).
Your light is now ready to use.
Replacing lamps
RISK OF ELECTRIC SHOCK!
First disconnect the light from the mains when replac-
ing the lamp. To do so, remove the fuse or switch off
the circuit breaker in the fuse box 0 position.
Allow the light to cool off completely.
Model 14101008L / 14100902L
Use the included suction cup
16
to replace the
defective lamp
15
. Push the suction cup
16
onto
the front face of the defective lamp
15
to do so.
Twist the defective lamp
15
out of the socket with
a ¼-turn counter-clockwise.
Remove the suction cup
16
by lightly pulling on
the side tab on the suction cup
16
.
Push the suction cup
16
onto the front face of
the new lamp
15
.
Insert the new lamp
15
into the socket and
secure with a ¼-turn clockwise. Check for cor-
rect seating.
Model 14122508L
Uninstall the glass plate
9
before replacing the
illuminant
15
. To do so, loosen the cap nuts
11
and remove the silicone rings
10
and
8
.
Remove the illuminant
15
from the socket with
a
turn counter-clockwise.
Use a clean, lint-free cloth to replace a bulb.
Carefully insert the new illuminant
15
in the
socket and secure with a
turn clockwise.
Check it is correctly positioned.
Place the silicone rings
8
and the glass plate
9
on the spacers
7
. Be sure the trim for the
glass plate faces outward. Please note the po-
sition of the lamp bases.
Secure the glass plate
9
by installing the sili-
cone rings
10
and installing the cap nuts
11
.
Be sure they are seated correctly.
Model 14101008L or 14122508L or
14100902L
Reinstall the fuse or switch on the circuit breaker
(Position I) inside the fuse box.
Your light is now ready to use.
Maintenance and Cleaning
RISK OF ELECTRIC SHOCK!
Disconnect the light from the mains circuit before
cleaning. To do so, remove the fuse or switch off
the circuit breaker in the fuse box (0 position).
RISK OF ELECTRIC SHOCK!
For electrical safety, never clean the light with water
or other liquids, or immerse it in water.
CAUTION! RISK OF BURNS DUE TO HOT
SURFACES! Allow the light to cool completely.
Do not use solvents, benzene or similar sub-
stances. They could damage the light.
