9 GB/IE/NI
Installation
Mounting the light
Move the cover
3
upward (Fig. A).
Use the mounting bracket
4
and screws
5
to mount the under-cupboard light.
Hold the mounting bracket against the desired
surface and mark the drill holes (Fig. A).
Now drill the mounting holes (ø approx.
2 mm, approx. 17 mm deep).
Position the mounting bracket according to
the predrilled holes and tighten the screws
(Fig. A).
The lamp arm can be fixed, if desired. To do
so, tighten the two screws on the swivel joint.
Connect the low voltage plug connection
9
with the LED driver
10
(Fig. C).
Mount the LED driver using the included
screws
11
(Fig. C).
Plug the mains plug
13
into the mains socket.
Your light is now ready to use.
Wall-mounting the light
Move the cover
3
upward (Fig. B).
Use the mounting bracket
4
, screws
8
and
the wall plugs
7
for wall mounting.
Hold the mounting bracket against the de-
sired surface and mark the drill holes (Fig. B).
Now drill the mounting holes (ø 6 mm, approx.
30 mm deep).
CAUTION! Ensure that you do not damage
any electrical cables, gas or water pipes
when you drill into the wall.
Insert the included wall plugs into the bores.
Position the mounting bracket according to
the predrilled holes, insert the screws into the
wall plugs, and tighten the screws (Fig. B).
The lamp arm can be fixed, if desired. To do
so, tighten the two screws on the swivel joint.
Connect the low voltage plug connection
9
with the LED driver
10
(Fig. C).
Mount the LED driver using the included
screws
11
(Fig. C).
Plug the mains plug
13
into the mains socket.
Your light is now ready to use.
Start-up
Never aim the LED beam at reflective surfaces,
people or animals. Failure to observe this
advice may result in eye irritation and / or
blindness in humans and animals. Even a
weak LED light beam can cause eye damage.
