Je bekijkt pagina 8 van 39
8 GB/IE
Before use
Charging the rechargeable batteries
Note: The rechargeable batteries inside the main unit are fully charged at delivery. However, they may
already have lost charge during transport from the manufacturer to the retail location. Therefore charge
the batteries prior to use. During summer, initial charging will take at least one day in constant sunlight.
Set the switch
12
to the „OFF“ position.
Note: In constant sunlight (depending on the season) drained batteries should take two to ten days
to charge.
Note: the built-in charging controller of the LED solar spotlight prevents the rechargeable batteries
from overcharging.
Replace the rechargeable batteries if light output does not improve after charging (Fig. C).
Assembly
Select a suitable place for installation.
Ensure that the motion detector will not be functionally inhibited at the desired place of installa-
tion due to obstacles or constantly moving objects.
Ensure that the light is mounted in a place with direct sunlight.
Ensure that the spotlight is not installed where there are strong temperature fluctuations, e.g. due
to heating devices.
Ensure that the spotlight is installed far away from unnatural light sources and in southern direction.
Ensure that the supplied screws and wall plugs are suitable for the type of wall. If not, use other
suitable screws and wall plugs. The manufacturer is not responsible for improper use of wall
connections.
Mounting the light
Ensure that the light is placed with the spotlight head upwards. Do not install the spotlight in any
other position.
Secure the light to a stable and solid surface according to the instruction in Fig. A
Note: The enclosed mounting material is suitable for ordinary masonry construction. Other wall
substrates may require other fastening materials. Seek specialist advice when in doubt.
After mounting, check that the main unit is fitted securely.
Start-up
Note:
The solar cell
1
also works as a twilight sensor, while the motion sensor
7
only responds to
movement.
When selecting the setup location for the solar cell
1
be sure the solar cell, just as the twilight
sensor, are not affected by other light sources, e.g. street lighting.
The switch
12
on the spotlight
2
(Fig. A) features the following functions:
Position „OFF“: Sensor
7
and spotlight
2
are off. In direct sunlight the rechargeable batteries
are charged by the solar cell
1
. Use this setting to charge drained batteries
(see „Charging the rechargeable
batteries“).
Position „ECO“: The spotlight automatically switches on or off once the solar cell
1
detects dusk
or dawn. To ensure a long life the LEDs will not be fully powered in this setting,
