26 GB
Start-up / Maintenance and Cleaning / Disposal / Warranty and ServicePreparation /Prior to installation / Start-up
and are only provided as a reference. The nature
of the material is determined by the individual local
conditions.
- Pencil / marking tool
- Voltage tester
- Screwdriver
- Electric drill
- Drill (ø 6 mm)
- Side cutting pliers
- Ladder
Prior to installation
Important: The electrical connection must be
performed by a qualified electrician or a person
trained in electrical installations. This person must
be familiar with the properties of the light and the
connection regulations.
Familiarise yourself with all the instructions and
diagrams in this manual, as well as with the light
itself, before you install it.
Before installation ensure that the circuit, to which
the light will be connected, is not energised. To
do so, remove the fuse or switch off the circuit
breaker in the fuse box 0 position.
Use the voltage tester to verify the de-energised
status.
Start-up
Mounting the light
Model 14100702L or 14100808L
Place the spacers
7
in the designated openings
on the connection housing
6
and secure the
spacer
7
with the screws
5
. Ensure they are
correctly seated.
Place one silicone ring
8
over each of the in-
stalled spacers
7
.
Place the glass plate
9
onto the spacers
7
.
Be sure the chrome trim on the disc faces down
(14100808L).
Secure the glass plate
9
by installing the silicone
rings
10
and securing it with the box nuts
11
.
Ensure the end cap is seated correctly.
Model 14100902L or 14101008L
Place the chrome plating
16
over the connection
housing
6
. Please note the position of the lamp
bases.
Place the spacers
7
over the designated open-
ings on the connection housing
6
and secure
the spacers
7
and chrome plating
16
using
the screws
5
. Ensure they are correctly seated
Place one silicone ring
8
over each of the in-
stalled spacers
7
.
Place the glass plate
9
onto the spacers
7
.
Be sure the chrome trim on the disc faces down.
Please note the position of the lamp bases.
Secure the glass plate
9
by installing the silicone
rings
10
and securing it with the box nuts
11
.
Ensure the end cap is seated correctly.
Model 14100702L or 14100808L or
14100902L or 14101008L
Remove the locating screws
3
visible at the
side of the connection housing
6
and remove
the mounting bracket
2
at the back.
Use the slotted holes on the mounting bracket
2
to mark the bores.
Now drill the fixing holes (approx. 6 mm, depth
approx. 30 mm). Be careful not to damage the
supply line.
Feed the power cord (external)
13
through the
cable guides
12
.
Insert the plugs
1
into the bores.
Fasten the mounting bracket
2
with the pro-
vided screws
4
.
Now connect the connection cable of the light
with the connection cable (external)
13
using
the terminal block
14
.
Note: be sure to correctly connect the individ-
ual leads on the mains cable (external)
13
: live
wire, black or brown = symbol L, neutral wire,
blue = symbol N, earth wire, green-yellow =
symbol
.
Now use the screws
3
to connect the light to
the mounting bracket
2
.
