7 GB/CY
Please read carefully through these operating
instructions before installing and using the product.
Keep all the safety advice and instructions in a
safe place for future reference!
Installation
Installing the tap
Note: To protect the parts from scratches while
being screwed together cover them with a damp
cloth or use plastic clamps.
Before you start installation turn off the main
water supply to prevent serious leakage of water.
Install the tap at the wall connection as shown
in Figure A.
Connecting the accessories
(shower head and shower hose)*:
Note: So that the parts do not get scratched while
being screwed together, protect them with a damp
cloth or use plastic clamps.
Screw an ordinary shower hose* firmly on to
the thread
12 a
.
Attach an ordinary shower head* to the shower
hose*.
Observe the installation instructions for the
accessories.
* (not included)
Operation
Bringing into use
Note: If the tap has not been used for a long period
flush the pipes through thoroughly in order to avoid
stagnation and build-up of residues in the drinking
water supply.
Open the main water supply.
Lift the control lever
7
and swivel it to the right
or left to regulate the strength or temperature
of the water flow.
Hot water:
Swivel the control lever to the left.
Cold water:
Swivel the control lever to the right.
Check that the mixer tap is working properly.
To do this, swivel the lever into all the possible
positions. Please check the connections regularly
for leaks.
Setting the temperature limiter
The cartridge
10
in this unit has a temperature limiter.
This function is not activated in the factory (neutral
setting).
CAUTION! Change the temperature limiter
setting only after the tap has been installed.
Turn off the main water supply.
Remove the cap
5
carefully by a small flat
screwdriver (see Fig. B).
Release the locking screw
6
by turning it
anticlockwise using a hexagonal key.
CAUTION! Do not take the screw completely
out; just loosen it until the control lever
7
can
be easily taken off.
Take off the control lever
7
.
Loosen the cartridge end ring
8
by hand, then
screw off the cartridge locking ring
9
by using
a pipe wrench.
Now pull the setting ring
11
upwards with the
help of a screwdriver.
Note: Do not remove the cartridge.
Place the setting ring
11
in the desired position
as shown in Fig. D.
Note: The setting ring
11
can limit the turning
angle of the handle, so that the amount of hot
water can be limited.
Tighten the cartridge locking ring
9
onto the
tap body
12
again by using a pipe wrench,
then tighten the cartridge end ring
8
by hand.
Place the control lever
7
back on to the tap
body
12
and tighten the locking screw by turn-
ing it clockwise using a hexagon socket screw key.
Press the cap
5
into the opening.
