15 GB/IE
In the event of a leakage of batteries / recharge-
able batteries, immediately remove them from
the product to prevent damage.
Only use the same type of batteries / recharge-
able batteries. Do not mix used and new
batteries / rechargeable batteries.
Remove batteries / rechargeable batteries if the
product will not be used for a longer period.
Risk of damage of the product
Only use the specified type of battery /
rechargeable battery!
Insert batteries / rechargeable batteries accord-
ing to polarity marks (+) and (-) on the battery /
rechargeable battery and the product.
Use a dry lint-free cloth or cotton swab to
clean the contacts on the battery / rechargea-
ble battery and in the battery compartment be-
fore inserting!
Remove exhausted batteries / rechargeable
batteries from the product immediately.
Functioning
The solar cell installed in the product converts sun-
light into electrical energy and stores it in one re-
chargeable battery. Switch on the product with the
ON / OFF button
15
. The product will automati-
cally light on as it begins to get dark. The in-built
light-emitting diodes are a very long-life and ener-
gy-saving light source. The light duration depends
on the amount of sunlight, the angle of light on the
solar cell and the temperature (the battery capacity
is temperature-dependent). A vertical angle of light
at temperatures above the freezing point is ideal.
The battery does not achieve maximum capacity
until after several charge and discharge cycles.
In summer a completely drained rechargeable bat-
tery takes about 2 to 4 days to fully recharge in
constant sunlight.
Operation
1. Take out the solar panel compartment.
2. Switch the ON / OFF button
15
to ON position,
the product will automatically switch on at dusk
(see Fig. C).
3. Put the solar panel compartment back into dec-
oration figure
1
. Insert the tail
2
and stand
7
to the main body (see Fig. B).
Setting up the product
(see Fig. B)
Insert the stand
7
to the Decoration figure
1
then use the secure screw
8
to fix it. Place the
ground spike
6
over the top of the stand
7
then anchor ground spike
6
to the ground to
fix it.
Model C:
Insert the tail
2
to the decoration figure
1
.
Model A and B:
Insert the tail
2
to the connector
3
, then use
hexagon screws
5
by hexagon key
4
to fix
it. After that, insert the connector
3
to the dec-
oration figure
1
upward or downward and fix
it with hexagon screw
5
too.
In order to achieve the best result, set the prod-
uct up in a place where the solar panel
9
will
get direct sunlight for as long as possible.
Make sure that the solar panel
9
is not influ-
enced by any other source of light such as
yard or street lighting as otherwise the light will
not come on in twilight.
The light automatically switches on in twilight
conditions and off again when normal outdoor
lighting conditions return.
Replacing the rechargeable
battery (see Fig. C)
The battery should be replaced every
12 months to ensure optimum performance.
