Je bekijkt pagina 47 van 100
47
GB/IE/NI/CY/MT
use other than intended or incorrect use.
This product uses a light source with a Class
F energy efciency rating.
z Specications supplied
1 LED outdoor spotlight
1 wall bracket (for mounting on building
walls or corners) inc. xings (4 wall plugs,
2 screws (10mm), 4 screws (25mm))
1 instruction manual
z Description of parts
1
LED module
2
Motion and twilight sensor
3
LUX control (for setting sensitivity of
twilight sensor)
4
TIME control (for setting the illumination
time)
5
SENS control (for setting the detection
range)
6
Terminal strip
7
Strain relief clamp
8
Household mains live conductor L
9
Household mains protective earth
conductor PE (green/yellow)
10
Household mains neutral conductor N
11
Gland nut
12
Cover plate
13
ON/OFF/AUTO button
14
Screw (cover plate)
15
Cable grommet
16
Wall bracket
17
Guide holes for xing screws (when
mounting on straight walls)
18
Guide holes for xing screws (when
mounting on corners)
19
Screw (25mm)
20
Wall plugs
21
Screw (10mm)
z Technical data
Model number: 1002-W/1002-G
Input power: max. 24W
Power supply:
220-240 V AC,
50/60 Hz
Dimensions:
approx. 190 x 230 x
200mm
Weight: 650 g
Luminous power: 1,900lm with diffusor
Beam width: 100 °
Max. projection
area:
294cm²
Protection class: IP44
Motion detector:
eld of view approx.
110°, range max. 12m
Rated ambient
temperature:
-21°C to +25°C
Mounting height: up to 3m
Suitable
conductor
cross-section for
power supply
terminal:
H05RN-F, 3x 1,0 mm²
z Safety instructions
Safety instructions
WARNING!
RISK OF FATAL INJURY AND
ACCIDENTS FOR INFANTS AND
CHILDREN! Never leave children
unsupervised with the packaging material.
There is a danger of suffocation from the
packaging material. Children often
underestimate the dangers. Always keep
children away from the product.
This product can be used by children aged
