B-5
OPERATION (INSTRUCTOR MODE)REALWELD
®
TRAINER
After all supplemental material has been added, select the red “X”
in the upper right corner of the supplemental material editor to apply
your changes to the WPS. See Figure B.17.
Once the supplemental material editor closes the WPS editor will
be updated with an icon to indicate that the WPS has supplemental
material attached. See Figure B.18.
When the WPS parameters have been entered, select the ‘Save’ icon
from the toolbar.
CURRICULUM
Select the ‘Curriculum’ icon on the left side of the screen to enter the
curriculum section.
The ‘Curriculum List’ will display all the curriculum’s that the
instructor has entered. Select any of the curriculum’s to show the
corresponding curriculum sequence. The curriculum sequence
displays the learning objectives that have been assigned to a
particular curriculum. See Figure B.19.
In the curriculum menu the instructor can add, edit or remove
curriculum’s from the list.
ADD A CURRICULUM
1. Using the touch screen monitor, select the ‘New’ icon on the left
side of the screen.
2. In the pop up window, select the text box area to bring up the
on-screen keyboard. Enter a name for the curriculum and select
the ‘Enter’ on the keyboard. See Figure B.20.
3. The ‘Curriculum Editor’ window will appear. In this window, the
instructor can add, remove and rearrange the order of learning
objectives associated with this curriculum. See Figure B.21.
Figure B.17 – Apply changes
Figure B.18 – Operation
Figure B.19 – Curriculum
Figure B.20 – New curriculum
Figure B.21 – Curriculum editor
