22 Document #: LIN_EOGO_IOM_24APERION_4605890_Rev1 - 01/24
Operation and Programming Section 3
Figure 4
2. The oven is now in pre-heat mode (Figure 5) and the oven
heaters will start-up. The temperature settings appear
on the screen. You will see the temperature of the oven
and the temperature increasing up to the set-point. The
conveyor does not move in pre-heat mode.
Figure 5
When the oven reaches the set-point temperature, the
conveyor belt will start to move. The display will show the
selected set-point temperature, fan speeds, and cook time
(Figure 6). If the oven has a split belt configuration, the display
will show the selected set-point temperature, fan speeds, and
cook times for both belts (Figure 7).
3. Oven Soak – allow the oven cavity to soak for an additional
5-10 minutes before loading food.
4. Load Food – The oven is now ready for cooking. Please
use the proper equipment to load and unload food from
the conveyor. The conveyor will be hot to the touch. Pans
or trays exiting the oven will be VERY HOT and are a burn
hazard. Please use an oven mitt, pan gripper or other
utensil to remove.
Figure 6
Figure 7
ECO MODE
Eco mode allows the operator to save energy by stopping
the conveyor belt and reducing fan speed, while maintaining
oven temperature. Immediate cooking after disengaging ECO
mode is possible.
1. Press the Leaf button on upper left side of the Recipe -
Ready screen (Figure 8). The screen will change to Eco
Mode (see Figure 9). The conveyor will stop moving while
the temperature in the cavity should remain unchanged.
2. To re-start the conveyor, press the X button on the Eco
Mode screen and the Recipe screen will re-appear.
Figure 8
Figure 9
MANUAL MODE
Manual mode allows the operator to change the temperature,
upper and lower fan speeds, and cook time to revise or create
a new recipe.
