Section 2 Installation
Document #: LIN_EOGO_IOM_24APERION_4605890_Rev1 - 01/24 19
Start-Up Checkout
You are now ready for the services to be connected. This
should be done by a qualified plumber, electrician, or
installer of your choice. For installation in the state of
Massachusetts: installation of this oven must be performed
by a licensed plumber or gas fitter. Refer to Utility
Specifications and Installation Requirements sections for
additional information.
Important
The manual shut-off valve must be installed so that the
test plug is on the oven side of the valve.
Start-Up Procedures
SMOKE CANDLE TEST VENTILATION SYSTEM
VERIFICATION
Performance will be evaluated during Start-up Checkout
by conducting a smoke candle test. The hood must capture
all smoke from the oven. This is required to assure proper
performance of the oven and to eliminate additional service
calls that occur when ambient temperatures are too high. In
all cases, the ambient temperature around the oven must be
less than 95°F/35°C when the oven is operating. In certain
localities, other chemical or gaseous methods of detecting
adequate capture will be the requirement to meet the local
code authority.
Oven Setup for this Test:
• This test is to be done on the bottom oven of a multiple
oven system, or a single oven.
• The conveyor must be off.
• The oven temperature must be set and operating at
550°F/288°C.
Test Procedure:
NOTE: Use Lincoln Smoke Candle #369361 (in Australia, an
alternate method of coloring the air may be used).
1. Wear heat resistant gloves to prevent burns to your
hands.
2. Put the smoke candle in a cake pan approximately
8 inches (200 mm) x 8 inches (200 mm) x 2 inches
(50 mm) deep or equivalent.
3. Light the fuse of the smoke candle and immediately put
the pan and candle into the center of the oven cavity, on
the conveyor belt. (Close the access window or door.)
4. Observe the smoke pattern coming out of the oven
openings and the collection of this smoke by the
ventilation system.
5. The ventilation system must capture all the smoke from
the oven.
Installation Checklist
DANGER
Check all wiring connections, including factory terminals,
before operation. Connections can become loose during
shipment and installation.
n
Warning
On completion of any installation or service work, test
for gas leaks before returning the equipment into service.
Never use matches, candles, or any other ignition source
to check for leaks. If gas odors are detected, shut off the
gas supply to the appliance at the main shut-off valve
and immediately contact the local gas company or an
authorized service agency for service.
DO NOT ATTEMPT TO OPERATE THE OVEN until connection
of utility service and installation has been fully inspected
(START-UP CHECKOUT) by a Factory Authorized Servicer or
a Lincoln Foodservice Products, LLC Service Representative.
This service is required by Lincoln Foodservice Products,
LLC in order to insure the oven(s) is properly installed and
in working order. The warranty becomes effective upon
verification of proper installation.
The warranty shall not apply if the oven is started up
and operated prior to the “START-UP CHECKOUT” being
performed by a Factory Authorized Servicer or a Lincoln
Foodservice Products, LLC Service Representative.
