CAUTION
Risk of injury or damage from the appliance tipping or the
door falling open!
If the additional adjustable foot on the base support is not
correctly positioned on the floor, there is a risk of the door
falling open or the appliance tipping. This can lead to injury
or property damage.
u
Unscrew the additional adjustable foot on the swap
bearing block as instructed.
u
Unscrew the adjustable foot Fig. 6 (B) on the swap
bearing block with the enclosed open-end spanner until it
rests on the floor.
u
Turn the adjustable foot Fig.6(B) 90° further.
w
The appliance is aligned.
12 After setting up
u
Take off the protective film from the exterior of the appli‐
ance.
u
Take off the protective film from the trim panels.
u
Take off the protective film from the trim panels and
drawer fronts.
u
Take off the protective film from the stainless steel rear
panel.
u
Remove all transport safety components.
u
Clean the appliance. (see operating instructions)
u
Note the type (model, number), appliance designation,
appliance/serial number, purchase date and dealer’s
address.
13 Disposing of packaging
WARNING
Danger of suffocation due to packing material and plastic
film!
u
Do not allow children to play with packing material.
The packaging is made of recyclable materials:
-
corrugated board/cardboard
-
expanded polystyrene parts
-
polythene bags and sheets
-
polypropylene straps
-
nailed wooden frame with polyethylene panel*
u
Take the packaging material to an official collecting
point.
14 Door hinge change
Tools
Fig.7
NOTICE
Risk of damage due to door collision!
Damage to the appliances with Side-by-Side positioning. If
you set up two appliances next to each other in a specific
Side-by-Sidearrangement, the door hinge of both appliances
is preset at the factory.
u
Side-by-Side positioning: Do not change the door hinge.
These sections apply for appliances with a soft stop mech‐
anism:
q
For appliances with a soft stop mechanism
q
For all appliances
Fig.8
Remember the reading direction.
14.1 Removing the upper soft stop
mechanism*
For appliances with a soft stop mechanism:*
Fig.9
u
Open the top door.
NOTICE
Risk of damage!
If the door seal is damaged, the door may fail to close prop‐
erly and the cooling will be inadequate.
u
Do not damage the door seal with the screwdriver!
u
Remove cover Fig.9(1).
After setting up
8 * Depending on model and options
