Maximum load per shelf

Appliance width 600mm 750mm

Grid shelves 45 kg 60 kg

Glass shelf 40 kg 40 kg

Wooden shelf 45 kg 60 kg

Drawer 20 kg 20 kg

Heavier loads may result in a slight bending of the

shelves.

Maximum total load and net weight

Model (see 4.2 Appliance

dimensions)

Maximum total

load

Net weight

SFTvh 1501 60 kg 39 kg

Net capacity

See net capacity on the type plate. (see 1.2 Overview of

the appliance and equipment)

Set-up conditions

Degrees of pollution (surrounding

the appliance)

PD2

Ambient temperature +10°C to +35°C

Maximum relative ambient moisture 75%, not condensing

Maximum operating elevation

(metres above sea level)

2000m

1500m(glass door)

Electrical values

Nominal voltage 220-240 V~

Electrical values

Frequency 50/60Hz

Connected load 2,0A

Maximum mains fluctuation +/-10%

Overvoltage categories II

Data as per DIN 13277 measured at a reference ambient

temperature of +25°C

Model

SFTvh

Energy

consump‐

tion (kWh/

24h)

Tempera‐

ture rise

during

mains

failure

(min)

Tempera‐

ture

homoge‐

neity (°K)

Temperature

constancy

(°K)

1501 0.72

169

2.2

7.8

Erwärmung Referenzkörper: von -25°C auf -10°C / Refer‐

enzkörper: 50ml Glasbehälter gefüllt mit 50ml Isopropanol

Measured at reference setpoint temperature of -25°C

9.2 Technical fault

Your appliance is designed and built to ensure it works reli‐

ably and has a long service life. In the unlikely event that

a fault occurs during operation, please check whether the

fault is due to an operating error. If this is the case, you will

be charged for the cost incurred even if this falls within the

warranty period.

You can fix the following faults yourself.

9.2.1 Appliance function

Defect

Cause Remedy

The appliance is

not working.

→ The appliance is not switched on.

Switch on the appliance.

→ The mains plug is not properly

plugged into the socket.

Check the mains plug.

→ There is something wrong with the

fuse in the socket.

Check fuse.

→ Power cut

Keep the appliance closed.

If necessary move the refrigerated/frozen items to

another fridge or freezer if the power is off for a

prolonged period.

→ The IEC socket is not plugged into

the appliance correctly.

Check the IEC socket.

Temperature is not

cold enough.

→ The appliance door is not closed

properly.

Close appliance door.

→ Ventilation is not sufficient.

Clear ventilation grille and clean it.

→ The ambient temperature is too

high.

Ensure the correct ambient conditions: (see1.4 Range of

use of appliance)

→ The appliance was opened too

many times or for too long.

Wait to see if the appliance goes back to the required

temperature by itself. If not, contact Customer Service.

(see 9.3 Customer Service)

→ The temperature is set incorrectly.

Set a colder temperature and check after 24 hours.

→ The appliance is too close to a heat

source (oven, radiator, etc).

Change where the appliance or the heat source are

located.

Customer help

* Depending on model and options 39
