Lift the pull-out board on the front right. Fig. 102(9)

Pull-out board is detached from the attachment at the

front.

Take out the pull-out board to the front. Fig. 102(10)

The pull-out board has been removed and you can clean

it. (see 9.3.4 Clean the components)

Removing the glass shelf from under the pull-out board

(see 8.3 Glass shelves)

8.2.2 Inserting the pull-out board with IceTower

Inserting the glass shelf from under the pull-out board

(see 8.3 Glass shelves)

Inserting the pull-out board

Fig. 103

Slide the rails in.

Fig. 104

Place the pull-out board in at an angle behind the front

lug.

Slide in at an angle. Make sure that the stop is behind the

lug on both sides. Fig. 104(11)

Lower the pull-out board at the front. Fig. 104(12)

Fig. 105

Push the pull-out board down at the front.

Pull-out board clicks into place.

Inserting the container

Ensure that the following conditions are met:

The pull-out board is inserted. (see Inserting the pull-out

board)

Fig. 106

Pull out the pull-out board.

Hold the pull-out board with one hand.

Note

The containers are shaped in a way that they cannot be

interchanged.

Place the container at an angle on the pull-out board.

Fig. 106(13)

Slide the container to the back at an angle. Fig. 106(14)

Place container in the front. Fig. 106(15)

Fig. 107

Insert hang-on tray Fig. 107(6) for ice cubes.

Slide in the pull-out board with (IceTower) container.

Fig. 107(16)

Pull-out shelf with IceTower is fully inserted.

8.3 Glass shelves

NOTICE

Impermissible removal of the glass panel above the

IceTower!

Damage to the IceMaker. The IceMaker is attached to the

glass panel above the IceTower.

Do not remove the glass panel above the IceTower.

You can remove the glass shelves under the drawers for

cleaning.

You can remove the glass shelves under the drawers to use

VarioSpace.

Features

* Depending on model and options 23
