Note
The energy consumption increases and the cooling power
goes down if ventilation is not sufficient.
u
Leave the bottom drawer in the appliance!
u
Always leave the fan air vents clear on the back wall!
8.1.1 Drawer on telescopic rails
The drawer runs on extendible rails (telescopic rails). There
are fully extendible telescopic rails and telescopic rails with
partial pull-out. Drawers which are fully extendible can be
pulled out fully from the appliance. Drawers with partial
pull-out cannot be removed fully from the appliance. The
system in your appliance depends on the type of appliance.
Drawer on glass shelf
The drawer guided on a glass shelf is a partial pull-out.
Removing drawer
Fig.88
u
Pull out drawer as far as it will go. Fig.88(1)
u
Lift drawer on the left. Fig.88(2)
u
Insert left rail. Fig.88(3)
Fig.89
u
Lift drawer on the right. Fig.89(4)
u
Insert right rail. Fig.89(5)
u
Remove drawer to the front. Fig.89(6)
Fig.90
If the rails are not yet fully inserted after removing the
drawer:
u
Push rails in completely.
Inserting drawer
Fig. 91
u
Slide rails in.
u
Place drawer on rails at an angle.
Fig.92
u
Lower drawer.
u
Slide in drawer to the back.
8.1.2 Top tilting drawer
When you pull out the top drawer, it tilts forward. This gives
you a better view into the drawer. The function depends on
the height of the appliance.
Removing drawer
Fig. 93
u
Pull out drawer as far as it will go.
u
Lift drawer at the front.
u
Lift drawer from below.
u
Remove drawer to the front.
Inserting drawer
Fig. 94
u
Guide drawer around the upper stoppers. Fig. 94(1)
u
Place drawer at an angle behind the lower stoppers onto
moulded rib. Fig. 94(2)
u
Lower drawer.
u
Slide to the back.
8.1.3 Drawer on moulded rib*
The drawer runs directly on the moulded rib. There are no
rails.
Removing drawer
Fig.95
u
Pull out drawer as far as it will go.
u
Lift up drawer at the front. Fig.95(1)
u
Remove drawer to the front. Fig.95(2)
Features
* Depending on model and options 21
