Fig.99
u
Remove the pull-out board.
u
Hold the pull-out board with one hand.
Note
The containers are shaped in a way that they cannot be
interchanged.
u
Place the container at an angle on the pull-out
board. Fig.99(13)
u
Slide in the container at an angle to the back.
Fig.99(14)
u
Place container at the front. Fig.99(15)
Fig. 100
u
Insert hang-on tray Fig. 100(6) for ice cubes.
u
Slide in the pull-out board with container (IceTower).
Fig. 100(16)
w
Pull-out board with IceTower is fully inserted.
8.3 Glass shelves
NOTICE
Impermissible removal of the glass panel above the
IceTower!
Damage to the IceMaker. The IceMaker is attached to
the glass panel above the IceTower.
u
Do not remove the glass panel above the IceTower.
You can remove the glass shelf under the drawers for
cleaning.
You can remove the glass shelf under the drawers to
use VarioSpace.
8.3.1 Removing / inserting the glass shelf
Make sure that the following requirements are fulfilled:
q
Glass shelf under the drawer: Drawer has been
removed. (see8.1 Drawers)
q
Pull-out board under IceTower: IceTower has been
removed. (see8.2 Pull-out board with IceTower)
Removing glass shelf
Fig. 101 Example illustration of glass shelf
u
Lift glass shelf at the front. Fig. 101(1)
u
Remove glass shelf to the front. Fig. 101(2)
Inserting the glass shelf
Fig. 102 Example illustration of glass shelf
u
Position glass shelf at an angle behind the stoppers.
(see Fig. 102)
u
Lower glass shelf.
u
Slide in glass shelf to the back.
8.4 IceMaker
The IceMaker is used exclusively for the production of
ice cubes in household quantities.
Equipment
* Depending on model and options 27
