u
Lower drawer.
u
Slide in drawer to the back.
8.1.2 Top tilting drawer
When you pull out the top drawer, it tilts forward. This
gives you a better view into the drawer. The function
depends on the height of the appliance.
Removing drawer
Fig.88
u
Pull out drawer as far as it will go.
u
Lift drawer at the front.
u
Lift drawer from below.
u
Remove drawer to the front.
Inserting drawer
Fig.89
u
Guide drawer around the upper stoppers. Fig.89(1)
u
Place drawer at an angle behind the lower stoppers
on the molded rib. Fig.89(2)
u
Lower drawer.
u
Slide to the rear.
8.1.3 Bottom drawer
The drawer is the lowest drawer in the appliance. It
runs directly on the molded rib. There are no rails.
Removing drawer
1
2
Fig.90
u
Pull out drawer as far as it will go.
u
Lift up drawer at the front. Fig.90(1)
u
Remove drawer to the front. Fig.90(2)
Inserting drawer
1
Fig. 91
u
Guide drawer in at an angle around the stoppers
Fig. 91(1).
u
Lower the drawer.
u
Slide in drawer to the back.
8.2 Pull-out board with IceTower
Fig. 92 Pull-out board with IceTower
(1)
IceMaker (3) Container for pizza or
alcoholic beverages,
for example
(2) Hang-on tray for ice
cubes
(4) Pull-out board
On the pull-out board are two tall containers
(IceTower). Ice cubes from the IceMaker are collected
and stored in the container Fig. 92 (2). The container
Fig. 92 (3) is suitable for storing tall foodstuffs or bever‐
ages such as pizzas or alcoholic drinks.
The pull-out board with IceTower is mounted on a glass
shelf with pull-out rails. You can dismantle the pull-out
board for cleaning.
8.2.1 Dismantling the pull-out board with
IceTower
Removing the container
Fig. 93
Equipment
* Depending on model and options 25
