Removing drawer
Fig. 21
u
Remove drawer as shown in the illustration.
Inserting drawer
Fig. 22
u
Insert drawer as shown in the illustration.
7.1.2 Drawer on telescopic rails*
The drawer runs on extendible rails (telescopic rails). There
are fully extendible telescopic rails and telescopic rails with
partial pull-out. Drawers which are fully extendible can be
pulled out fully from the appliance. Drawers with partial
pull-out cannot be removed fully from the appliance. The
system in your appliance depends on the type of appliance.
Drawer on glass shelf
The drawer guided on a glass shelf is a partial pull-out.
Removing drawer
Fig. 23
u
Pull out drawer as far as it will go. Fig. 23 (1)
u
Lift drawer on the left. Fig. 23 (2)
u
Insert left rail. Fig. 23 (3)
Fig. 24
u
Lift drawer on the right. Fig. 24 (4)
u
Insert right rail. Fig. 24 (5)
u
Remove drawer to the front. Fig. 24 (6)
Fig. 25
If the rails are not yet fully inserted after removing the
drawer:
u
Push rails in completely.
Inserting drawer
Fig. 26
u
Slide rails in.
u
Place drawer on rails at an angle.
Fig. 27
u
Lower drawer.
u
Slide in drawer to the back.
7.1.3 Top tilting drawer*
When you pull out the top drawer, it tilts forward. This gives
you a better view into the drawer. The function depends on
the height of the appliance.
When you remove the tilting drawers, you can use the glass
shelf below them as a storage shelf.
Removing drawer
Fig. 28
u
Pull out drawer as far as it will go.
u
Lift drawer up at the front and at the same time push up
at the back from below.
u
Remove drawer to the front.
Inserting drawer
Fig. 29
u
Position drawer as shown.
w
The drawer rests on the glass panel.
u
Lift drawer slightly from below at the back and slide over
the lip.
u
Slide in drawer to the back.
Features
* Depending on model and options 15
