8.12.2 Removing the flexible ice compartment
divider
Make sure that the following requirements are fulfilled:
❑
Ice cube drawer is removed. (see8.6 Drawers)
Fig. 149
► Lift the rear part of the ice compartment divider.
Fig. 149(1)
► Remove the ice compartment divider upwards. Fig. 149(2)
8.12.3 Putting in the flexible ice compartment
divider
Make sure that the following requirements are fulfilled:
❑
Ice cube drawer is removed. (see8.6 Drawers)
Fig. 150
► Insert the front part of the ice compartment divider.
Fig. 150(1)
► Lower the rear part of the ice compartment divider to the
drawer bottom. Fig. 150(2)
9 Maintenance
9.1 FreshAir carbon filter
The FreshAir carbon filter is in the compartment above the
fan.
It guarantees the best air quality.
❑
Replace the carbon filter every 6 months.
When the reminder is set, a message on the display
prompts you to change it.
❑
The carbon filter can be disposed of with the regular
household waste.
Note
FreshAir activated charcoal filters can be purchased
from the Liebherr-Hausgeräte store at home.liebherr.com/
shop/de/deu/zubehor.html.
9.1.1 Removing the FreshAir carbon filter
Fig. 151
► Pull out the compartment Fig. 151(1).
► Remove the carbon filter Fig. 151(2).
9.1.2 Inserting the FreshAir carbon filter
Fig. 152
► Insert the carbon filter as shown in the diagram
Fig. 152(1).
▷ The carbon filter clicks into place.
If the carbon filter is pointing downwards:
► Push the compartment in Fig. 152(2).
▷ The carbon filter is now ready for use.
9.2 Disassembling / assembling pull-
out systems
9.2.1 Notes on disassembly
You can disassemble some of the pull-out systems for
cleaning. Your appliance can contain a variety of pull-out
systems.
The following pull-out systems can be disassembled or
cannot be disassembled:
Pull-out system
can be disassembled/
cannot be disassembled
Drawer on appliance base or
glass shelf
cannot be disassembled
Drawer on rails cannot be disassembled
Fully extendible* cannot be disassembled*
Fridge section partial pull-out* cannot be disassembled*
9.3 Compartment lid for EasyFresh Safe
You can remove the compartment lid for cleaning.
Maintenance
30 * Depending on model and options
