Je bekijkt pagina 4 van 12
4 | EN Copyright © Liberty Pumps, Inc. 2022
All rights reserved. 6850000E
Do not dispose of materials such as paint thinner or other
chemicals down drains. Doing so could chemically attack and
damage pump system components and cause product
malfunction or failure.
Submersible Pump—do not run dry.
The Uniform Plumbing Code® states that sewage systems
shall have an audio and visual alarm that signals a
malfunction of the system, to reduce the potential for
property damage.
Keep pump upright.
At no time shall the pump be stored within an incomplete wet
pit. The pump shall not be placed into the pit until it can be
fully operational.
Do not allow the pump to freeze.
Model Specifica tions
For complete listing of models and their specifications, refer to
www.LibertyPumps.com/About/Engineering-Specs. Pump
nameplate provides a record of specific pump information.
Inspection a nd Stora ge
Initial Inspection
The pump should be immediately inspected for damage that may
have occurred in shipment.
1. Visually check the pump and any spare parts for damage.
2. Check for damaged electrical wires, especially where they exit
the motor housing.
Contact Liberty Pumps customer service to report any damage or
shortage of parts.
Storage Before Use
Protect the power and control cords from the environment.
Unprotected power and control (switch) cords can allow water
to wick through ends into pump or switch housings, causing
surroundings to become energized.
At no time shall the pump be stored within an incomplete wet
pit. The pump should not be placed into the pit until it can be
fully operational.
Do not allow the pump to freeze.
XLSG/XLSGX-Series Omnivore grinder pumps are shipped from
the factory ready for installation and use. The pump should be held
in storage if the pump station is not complete.
If storage is necessary, the pump should remain in its shipping
container. It should be stored in a warehouse or storage shed that
has a clean, dry temperature-stable environment where the pump
and its container are covered to protect it from water, dirt,
vibration, etc. The cord ends must be protected against moisture.
Uninstalled pumps that are idle for greater than three months
should have impellers and cutters manually rotated once a month
to lubricate the seals.
Pump Design
XLSG/XLSGX-Series grinder pumps are designed for continuous
underwater operation. The motor and pump form a close coupled,
watertight unit. The induction motor is insulated against heat and
moisture in accordance with Class F 311°F (155°C) regulations.
The motor is protected against damage from water entry by two
mechanical seals. The lower seal is 2-piece, silicon carbide/silicon
carbide and the upper seal is unitized graphite impregnated silicon
carbide.
The impeller and volute are designed for efficient flow
characteristics and clog-free operation. The hardened cutters
grind solids and fibrous matter into small particles that can be
safely pumped through small diameter piping.
General Information
Before installation, read these instructions carefully. Each
pump is individually factory tested to ensure proper
performance. Closely following these instructions will
eliminate potential operating problems, assuring years of
trouble-free service.
The XLSG/XLSGX-Series pumps are to be used for handling
septic tank effluent, sewage, and drain (storm) water.
Provide pump serial number in all correspondence.
Pumps are certified by CSA Group to CSA
®
, UL
®
, and FM
standards for use in hazardous locations with division
classification of Class 1, Division 1, Groups C and D; or as
zone classified Class 1, Zone
1, and Groups IIA and IIB.
Pumps must be serviced at a qualified hazardous motor
enclosure repair facility approved by Liberty Pumps. Any
unauthorized field repairs void warranty and hazardous
location ratings. Contact Liberty Pumps at 1-800-543-2550
to locate the closest authorized repair facility.
Operating Constraints
It is extremely important to verify that the pump has been
sized correctly for the intended installation. The operating
point of the pump must lie within the acceptable range as
outlined by the applicable Liberty Pumps performance chart.
Operating the pump outside of the recommended range
can invalidate the CSA Certification of the pump and can
also cause damage and premature failure. Operating
outside of the recommended range can cause the pump to
exceed its rated nameplate amp draw, which will void the
pump certification. It can also cause motor overheating,
cavitation, excessive vibration, clogging, and poor energy
efficiency.
RISK OF ELECTRIC SHOCK
