4 | EN Copyright © Liberty Pumps, Inc. 2023
All rights reserved. 2138000H
NightEye
Configuration
If the device is NightEye enabled, download the NightEye app from
the Apple® App or Google® Play store. Follow the directions
provided in the NightEye app to configure the device.
Alarm Testing
Sump Pump Sensor
This switch is a self-contained unit.
The internal float may not be visible
from the outside of the switch
housing. The switch should be placed
such that the activation point (the
bump on the right) is slightly higher
than the pump activation point.
1. In order to test the proper
operation of the float switch, we
recommend raising the water
level in your sump pit above its
normal operating level. When the
water level reaches the lowest
mark on the side of the float housing, the alarm will activate.
Alternately, a cup of water can be used to confirm float
operation. Raise the cup of water up to the float, and
submerse the float past the bump on the right. This will
trigger the alarm.
2. Once alarm begins to sound, it will continue to sound until the
water level is lowered. The audible alarm can be silenced using
the Silence button on the front of the device. The alarm will
stay silenced for 6 hours after the Silence button is pressed.
3. Once testing is complete, lower the water level in the pit back
to its normal range.
Sewage Pump Sensor
1. Manually tip the float up.
2. Once alarm begins to sound, it will continue to sound until the
float is tipped down. The audible alarm can be silenced using
the Silence button on the front of the device. The alarm will
stay silenced for 6 hours after the Silence button is pressed.
3. Lower the float back to its resting position to reset the alarm.
Auxiliary Contacts
This device comes equipped
with auxiliary contacts. These
contacts can be used to
integrate the output of this
alarm with an existing home
monitoring system.
Contact Rating: Class 2,
24 VDC/VAC (50/60 HZ)
500 mA maximum.
Operation and Maintenance
Once the alarm unit has been configured and tested, it is ready for
operation.
In the event that an alarm condition is detected by the system, the
audible and visual alarms will activate. The automatic reset feature
of the alarm will turn the audible and visual alarms off once the
condition has been corrected.
The following is a list of regular maintenance tasks:
1. Test the alarm system every 6 months. Follow the procedure
outlined in Alarm Testing.
2. When the 9V battery is low, the alarm will emit a short chirp
about twice per minute. The 9V battery should be replaced
any time the yellow “low battery” indicator on the alarm unit is
lit or every 12 months.
Warranty
Liberty Pumps Wholesale Products Limited
Warranty
Liberty Pumps, Inc. warrants that Liberty Pumps wholesale
products are free from all factory defects in material and
workmanship for a period of three (3) years from the date of
purchase (excluding* batteries and “Commercial Series” models).
The date of purchase shall be determined by a dated sales receipt
noting the model and serial number of the pump. The dated sales
receipt must accompany the returned pump if the date of return is
more than three years from the date of manufacture noted on the
pump nameplate.
The manufacturer's sole obligation under this Warranty shall be
limited to the repair or replacement of any parts found by the
manufacturer to be defective, provided the part or assembly is
returned freight prepaid to the manufacturer or its authorized
service center, and provided that none of the following
warranty-voiding characteristics are evident:
The manufacturer shall not be liable under this Warranty if the
product has not been properly installed, operated, or maintained
per manufacturer instructions; if it has been disassembled,
modified, abused, or tampered with; if the electrical cord has been
cut, damaged, or spliced; if the pump discharge has been reduced
in size; if the pump has been used in water temperatures above
the advertised rating; if the pump has been used in water
containing sand, lime, cement, gravel, or other abrasives; if the
product has been used to pump chemicals, grease, or
hydrocarbons; if a non-submersible motor has been subjected to
moisture; or if the label bearing the model and serial number has
been removed.
Liberty Pumps, Inc. shall not be liable for any loss, damage, or
expenses resulting from installation or use of its products, or for
indirect, incidental, and consequential damages, including costs of
removal, reinstallation or transportation.
There is no other express warranty. All implied warranties,
including those of merchantability and fitness for a particular
purpose, are limited to three years from the date of purchase.
This Warranty contains the exclusive remedy of the purchaser,
and, where permitted, liability for consequential or incidental
damages under any and all warranties are excluded.
*Liberty Pumps, Inc. warrants StormCell
®
batteries for 1 year from
date of purchase, and warrants that pumps of its Commercial
Series are free from all factory defects in material and
workmanship for a period of 18 months from the date of
installation or 24 months from the date of manufacture,
whichever occurs first, and provided that such products are used
in compliance with their intended applications as set forth in the
technical specifications and manuals.
alarm
float
“on”
location
1–2–3
1: Normally Open
2: Common
3: No Connection
