11
INSTALLATION
ENGLISH
maintained between the cooktop hob and the
range hood above it.
Oven
Drawer
a
Refer to Rangehood manufacturers clearance
instructions
b
Min. 15 mm
c
Min. 20 mm
d
Air intake
e
Air exit 5 mm
f
Min. 10 mm
WARNING
•
Ensuring Adequate Ventilation
Make sure the hob is well ventilated and that air
inlet and outlet are not blocked. In order to avoid
accidentally touching the hot bottom of the hob,
or unexpected electric shock during operation, it
is necessary to fit a wooden insert, fixed by
screws, at a minimum distance of 15 mm from
the bottom of the hob. Follow the requirements
below.
• There are ventilation holes around outside of the
hob. YOU MUST ensure these holes are not
blocked by the worktop when you put the hob
into position.
• The glue, which join the plastic or wooden
material to the furniture has to resist to 150 ℃ to
avoid the unstuck of the paneling.
Min. 15 mm
Max. 5 mmMax. 5 mm
