Step 1. Disconnect the battery pack cable from the system board.

Attention: Use your fingernails to pull the connector to unplug it. Do not pull the cable.

Step 2. Remove the SSD thermal pad

Figure 10. Remove the SSD thermal pad

Step 3. Remove one screw and then remove the SSD module by pulling it away from the slot.

Figure 11. Remove the SSD module

Screw specifications Number of screws

M2 x L1.8 1

Step 4. Remove the SSD bracket.

Figure 12. Remove the SSD bracket

Chapter 4. Removing a FRU or CRU 35
