Remove the battery pack

Make sure the following FRU (or CRU) has been removed.

“Remove the lower case” on page 32

Step 1. Disconnect the battery pack cable from the system board, remove five screws and then remove the

battery pack.

Attention: Use your fingernails to pull the connector to unplug it. Do not pull the cable.

Figure 8. Remove the battery pack

Screw specifications

Number of screws

M2 x L4

5

Step 2. Remove the battery pack mylar.

Figure 9. Remove the battery pack mylar

Go to https://support.lenovo.com/partslookup to look up the Lenovo part number of the following replacement

part:

Battery pack

Battery pack mylar

Remove the solid-state drive (SSD) module (2242)

Make sure the following FRU (or CRU) has been removed.

“Remove the lower case” on page 32

34

Hardware Maintenance Manual
