Screw specifications Number of screws
M2 x L6
7
M2 x L4 4
Step 3. Pry up the latches and then remove the lower case.
Figure 6. Pry up the latches and remove the lower case
Go to https://support.lenovo.com/partslookup to look up the Lenovo part number of the following replacement
part:
Lower case
Remove the battery pack
Make sure the following FRUs (or CRUs) have been removed.
“Remove the lower case” on page 30
Step 1. Disconnect the battery pack cable from the system board. Remove two screws and then remove
the battery pack.
Attention: Use your fingernails to pull the connector to unplug it. Do not pull the cable.
Figure 7. Remove two screws and then remove the battery pack
Chapter 4. Removing a FRU or CRU 31
