Figure 58. Remove two screws and then open the hinge
Screw specifications Number of screws
M2.5 x L5 2
Step 2. Disconnect the I/O board cable from the system board. Remove one screw and then remove the I/
O board with cable.
Figure 59. Remove the I/ O board with cable
Screw specifications
Number of screws
M2 x L3.5 2
Step 3. Separate the I/O board cable from the I/O board.
Chapter 4. Removing a FRU or CRU 63
