Figure 56. Disconnect the fan cable from the system board
Step 3. Remove three screws and then remove the fan.
Figure 57. Remove three screws and then remove the fan.
Screw specifications Number of screws
M2 x L5 3
Go to
https://support.lenovo.com/partslookup to look up the Lenovo part number of the following replacement
part:
Fan
Remove the I/O board module
Make sure the following FRU (or CRU) has been removed.
“Remove the lower case” on page 54
“Remove the fan” on page 61
Step 1. Remove two screws and then open the hinge.
62
Hardware Maintenance Manual
