Figure 22. Disconnect the fan cable from the system board
Step 3. Remove three screws and then remove the fan.
Figure 23. Remove three screws and then remove the fan.
Screw specifications
Number of screws
M2 x L5 3
Go to
https://support.lenovo.com/partslookup to look up the Lenovo part number of the following replacement
part:
Fan
Remove the I/O board module
Make sure the following FRU (or CRU) have been removed.
“Remove the lower case” on page 34
“Remove the fan” on page 42
Step 1. Remove two screws and then open the hinge.
Chapter 4. Removing a FRU or CRU 43
