“Remove the lower case” on page 29
Step 1. Disconnect the battery pack cable from the system board, remove two screws, and remove the
HDMI bracket.
Attention: Use your fingernail to pull the connector to unplug it. Do not pull the cable.
Figure 25. Disconnect the battery pack cable, remove two screws, and remove the HDMI bracket
Screw specifications Number of screws Torque force (kgf.cm)
M2 × L5 2 1.85 ± 0.15
Go to
https://support.lenovo.com/partslookup to look up the Lenovo part numbers of the following
replacement part:
HDMI bracket
Remove the DC-in bracket
Make sure the following FRU (or CRU) has been removed.
“Remove the lower case” on page 29
Step 1. Disconnect the battery pack cable from the system board. Remove two screws and then remove
the DC-in bracket.
Attention: Use your fingernail to pull the connector to unplug it. Do not pull the cable.
Chapter 4. Removing a FRU or CRU 43
