Figure 23. Disconnect the battery pack cable, peel off the Wi-Fi card mylar and disconnect the Wi-Fi antennas
Step 2. Remove one screw and then remove the Wi-Fi card.
Figure 24. Remove one screw and the Wi-Fi card
Screw specifications
Number of screws
Torque force (kgf.cm)
M2 × L2 1 1.85 ± 0.15
Go to
https://support.lenovo.com/partslookup to look up the Lenovo part numbers of the following
replacement parts:
Wi-Fi card
Wi-Fi card mylar
Remove the HDMI bracket
Make sure the following FRU (or CRU) has been removed.
42
Lenovo ThinkBook 16p Gen 5 Hardware Maintenance Manual
