Figure 19. Remove the I/O board with the CMOS battery
Screw specifications
Number of screws
M2.0 x L4 3
Step 4. Disconnect the CMOS battery from the I/O board and then remove the CMOS battery.
Figure 20. Remove the CMOS battery
Go to https://support.lenovo.com/partslookup to look up the Lenovo part numbers of the following
replacement parts:
I/O board
CMOS battery
Remove the fingerprint board cable
Make sure the following FRUs (or CRUs) have been removed.
“Remove the lower case” on page 34
“Remove the solid-state drive (SSD) and solid-state drive (SSD) bracket” on page 36
“Remove the I/O board and the CMOS battery” on page 41
Step 1. Disconnect the fingerprint board cable from the fingerprint board and then remove the fingerprint
board cable.
42
Hardware Maintenance Manual
