Thermal module mylar
Remove the I/O board and the CMOS battery
Make sure the following FRUs (or CRUs) have been removed.
“Remove the lower case” on page 34
“Remove the solid-state drive (SSD) and solid-state drive (SSD) bracket” on page 36
Step 1. Remove three screws and then open the hinge.
Figure 17. Remove three screws and then open the hinge
Screw specifications
Number of screws
M2.5 x L5 3
Step 2. Disconnect the I/O board cable and fingerprint board cable from the I/O board.
Figure 18. Disconnect the I/O board cable and fingerprint board cable from the I/O board
Step 3. Remove three screws and then remove the I/O board with the CMOS battery.
Chapter 4. Removing a FRU or CRU 41
