Step 3. Remove the SSD by pulling it away from the slot.
Figure 8. Remove the SSD
Step 4. Peel off the SSD mylar.
Figure 9. Peel off the SSD mylar
Step 5. Remove one screw and then remove the SSD and SSD bracket.
Figure 10. Remove the SSD and SSD bracket
Screw specifications
Number of screws
M1.6 x L1.8 1
Go to
https://support.lenovo.com/partslookup to look up the Lenovo part numbers of the following
replacement parts:
Solid-state drive (SSD)
Solid-state drive (SSD) bracket
Remove the Wi-Fi card
Make sure the following FRU (or CRU) has been removed.
“Remove the lower case” on page 34
Step 1. Disconnect the battery pack cable from the system board.
Attention: Use your fingernails to pull the connector to unplug it. Do not pull the cable.
Step 2. Peel off the thermal module tape. Detach the main and auxiliary antenna cable connectors. Remove
one screw and then remove the Wi-Fi card by pulling it away from the slot.
Chapter 4. Removing a FRU or CRU 37
