Figure 6. Remove six screws and remove the battery pack
Screw specifications
Number of screws
M2.0 x L4 6
Go to
https://support.lenovo.com/partslookup to look up the Lenovo part number of the following replacement
part:
Battery pack
Remove the solid-state drive (SSD) and solid-state drive (SSD) bracket
Make sure the following FRU (or CRU) has been removed.
“Remove the lower case” on page 34
Step 1. Disconnect the battery pack cable from the system board.
Attention: Use your fingernails to pull the connector to unplug it. Do not pull the cable.
Step 2. Peel off the tape and then remove one screw.
Figure 7. Remove one screw
Screw specifications
Number of screws
M1.6 x L1.8 1
36
Hardware Maintenance Manual
