Figure 9. Remove one screw and the Wi-Fi card
Label Thread
Length (mm) Torque (kgf.cm) Quantity
4
M2 3.0 1.85 ± 0.15 1
Go to
https://support.lenovo.com/partslookup to look up the Lenovo part numbers of the following
replacement parts:
Wi-Fi card
Wi-Fi mylar
Remove the 2242 solid-state drive
Make sure the following FRUs (or CRUs) have been removed.
“Remove the lower case” on page 29
Step 1. Disconnect the battery pack cable from the system board (1).
Attention: Use your fingernail to pull the connector to unplug it. Do not pull the cable.
Chapter 4. Removing a FRU or CRU 33
