Figure 13. Disconnect the battery pack cable, remove one screw, and remove the 2280 solid-state drive
Screw specifications
Number of screws Torque
M2 × L3 1
1.85 ± 0.15 kgf-cm
Note: The product supports up to two solid-state drives. Remove both if needed.
Go to
https://support.lenovo.com/partslookup to look up the Lenovo part numbers of the following
replacement part:
2280 solid-state drive
Remove the CMOS battery
Make sure the following FRUs (or CRUs) have been removed.
“Remove the lower case” on page 30
Step 1. Disconnect the battery pack cable from the system board.
Attention: Use your fingernail to pull the connector to unplug it. Do not pull the cable.
Step 2. Disconnect the CMOS battery cable from the system board and remove the CMOS battery.
Chapter 4. Removing a FRU or CRU 37
