Figure 54. Remove the LCD bezel
Note: The LCD bezel is fragile and should be replaced if damaged.
Screw specifications
Number of screws
M1.6 × L4.0 (for 14–inch models)
6
M2 × L3.5 (for 16–inch models)
6
Go to
https://support.lenovo.com/partslookup to look up the Lenovo part numbers of the following
replacement part:
LCD bezel
Remove the hinges
Make sure the following FRUs (or CRUs) have been removed.
“Remove the lower case” on page 28
“Remove the LCD unit” on page 55
“Remove the hinge cover” on page 60
“Remove the LCD bezel” on page 61
Step 1. Remove six screws. Then, remove the hinges.
62
IdeaPad Slim 5 (14″, 8), IdeaPad Slim 5i (14″, 8), IdeaPad Slim 5 (16″, 8), and IdeaPad Slim 5i (16″, 8) Hardware Maintenance
Manual
