Figure 7. Remove the lower case
Go to https://support.lenovo.com/partslookup to look up the Lenovo part number of the following replacement
part:
Lower case
Remove the battery pack and battery pack cable
Make sure the following FRU (or CRU) has been removed.
“Remove the lower case” on page 28
Step 1. Disconnect the battery pack cable from the system board.
Attention: Use your fingernails to pull the connector to unplug it. Do not pull the cable.
Step 2. Remove two screws and then remove the battery pack.
Figure 8. Remove the battery pack
Screw specifications Number of screws Torque force (kgf.cm)
M2 x L5 2 1.85±0.15
Step 3. Remove the battery pack cable.
Chapter 4. Removing a FRU or CRU 29
