Digital Hybrid Wireless Belt-Pack Transmitters
Rio Rancho, NM 13
Transmitter Models LCD menu item
SMWB/SMDWB/X:
• Digital Hybrid Wireless
®
: NA Hybr
• Mode 3:* Mode 3
• 200 Series: 200 Mode
• 100 Series: 100 Mode
• Mode 6:* Mode 6
• Mode 7:* Mode 7
• IFB Series: IFB Mode
Modes 3, 6 and 7 work with certain non-Lectrosonics
models. Contact the factory for details.
Selecting Step Size
This menu item allows frequencies to be selected in
either 100 kHz or 25 kHz increments.
Rolloff
Compat
StepSiz
Phase
StepSiz
100 kHz
25 kHz
StepSiz
100 kHz
25 kHz
If the desired frequency ends in .025, .050 or .075 MHz,
the 25 kHz step size must be selected.
Selecting Audio Polarity (Phase)
Audio polarity can be inverted at the transmitter so the
audio can be mixed with other microphones without
comb ltering. The polarity can also be inverted at the
receiver outputs.
Rolloff
Compat
StepSiz
Phase
Phase
Pos.
Neg.
Setting Transmitter Output Power
The output power can be set to:
SMWB/SMDWB, /X
• 25, 50 or 100 mW
/E01
• 10, 25 or 50 mW
Compat
StepSiz
Phase
TxPower
TxPower
25 mW
50 mW
100 mW
Setting Scene and Take Number
Use UP and DOWN arrows to advance Scene and Take
and MENU/SEL to toggle. Press the BACK button to
return to menu.
Sc&Take
Scene 1
Ta ke 5
TxPower
Sc&Take
Ta kes
Naming
Recorded File Naming
Choose to name the recorded les by the sequence
number or by the clock time.
Naming
Seq #
Clock
TxPower
Naming
SD Info
Default
SD Info
Information regarding the microSDHC memory card
including space remaining on card.
TxPower
Naming
SD Info
Default
[SMWB ]
Max Rec
E.........................F
0/ 14G
Fuel gauge
Storage used
Storage capacity
Available recording
time (H : M : S)
Restoring Default Settings
This is used to restore the factory settings.
TxPower
Naming
SD Info
Default
Default
settings
No
Ye s
