M2T, M2TND, M2T/E01, M2TND/E01, M2T/E02, M2T/E06
LECTROSONICS, INC.
20
Wireless Designer
Software
Download the Wireless Designer software installer from
the web sites under the SUPPORT tab at:
http://www.lectrosonics.com
Once the software is installed, updates are available by
simply clicking on “Check for updates” in the Help Menu.
Crreate, Edit, Store Flexlists in
Wireless Designer
Starting with Wireless Designer v2.1.0 for Mac or PC,
users now have the ability to create, load, save and send
Flexlists to receivers via an M2T-type device. Flexlists
now include an optional compatibility mode setting,
allowing Flexlist entires for receivers operating in dierent
compatibility modes.
NOTE: These functional enhancements are
available with M2T firmware update
M2T v4.0.03 (SUPER)/v6.00 (FPGA, H/W p20-v0 &
v1)/v7.00 (FPGA, H/W v2 & v3) and later.
Firmware Update
Instructions
Firmware updates are made with a le downloaded from
the web site and the M2T connected via USB.
The USB port on the transmitter requires a micro-B male
plug on the connecting cable. The other end of the cable
would normally be a USB A-type or C-type male con-
nector to t the most common type of USB jack used on
computers.
Refer to Help in Wireless Designer software for the pro-
cedure.
Specications
RF Power Output: • Two carriers; two audio channels each
• M2T, M2T/E01, M2T/E01: Power adjustable
on each carrier to 10, 25 or 50 mW
M2T/E06: Power adjustable on each
carrier to 20, 50 or 100 mW EIRP
Antenna Output: 2 x BNC sockets
Operating Frequencies:
M2T (A1B1) 470.100 – 607.975 MHz
M2T/E01 (A1B1) 470.100 - 614.375 MHz
M2T/E01-B1C1 537.600 - 691.175 MHz
M2T/E02 470.150 - 614.375 MHz
M2T/E06 520.000 - 614.375 MHz
NOTE: It’s the user’s responsibility to select the approved
frequencies for the region where the transmitter is operating
Operating Temperature
Range: Celsius: -20° - 40°
Farenheit: -5° - 104°
Frequency Selection
Steps: 25 kHz
Frequency Stability: ± 0.002%
Modulation: 8 PSK
Emission
Designator: 200KG7E
Spurious Radiation: Compliant with ETSI EN 300 422-1
Encryption: AES 256 bit CTR mode, when loaded
withv3.Xrmware
Equivalent input
Noise: –128 dBV
Latency: (overall system)
Digital Source: 1.0 ms plus Dante network (on Dante unit)
Analog Source: <1.8 ms
Audio Frequency
Response: 10 Hz – 11.5 kHz, -1 dB
Audio Input: -10 dBV or +4 dBu settings w/ ±5 dB trim
Audio Input Jack: 4 x combo XLR/TRS connectors
Input impedance: Line: 2k Ohm
Dante Connection: 2 x RJ45, 4 audio RX channels, internally routable
Ethernet Connection:RJ45
USB Connection: MicroUSBonfrontpanelforrmwareupdates
IRDA: IR transceiver for sync of receivers
Headphone jack 3.5 mm stereo jack
Power
Requirements: 9-18 VDC
Power Consumption
: 11 Watts
Weight: 2.2 lbs (997.903 grams)
Dimensions: Height: 1.750 in. / 44.45 mm
Width: 8.375 in. / 212.7 mm
Depth: 7.750 in. / 196.8 mm
Origin: Designed and manufactured in the USA
Specications subject to change without notice.
