Digital IEM Receiver
Rio Rancho, NM 15
Vol. Taper
Choose between Log or
Linear taper volume control.
Compat. Mode
Compatibility mode is available to allow the receiver to
operate with IFB (FM). Icon on main screen is shown
when IFB (FM) Mode is active. The M2Ra is
compatible with Lectrosonics Hybrid transmitters in
IFB mode.
Lock/Unlock
The front panel controls can
be locked to prevent unwanted
changes. To lock/unlock, hold
UP + DOWN.
Locale
North America (NA) and
Australia (AU) have certain
frequency restrictions, and
the restricted frequencies
are not available in
SmartTune. When chosen,
these locales include the
following available frequency
selections in SmartTune:
NA: 470.100 - 607.950 MHz
EU: 470.100 - 614.375 MHz
A1B1: AU: 520.000 - 614.375 MHz
JA: 470.150 - 614.375 MHz
EU: 537.600 - 691.175 MHz
B1C1: AU: 537.600 - 691.175 MHz
JA: 537.600 - 691.175 MHz
About M2Ra
Displays general information
about the M2Ra, including
serial number and the ver-
sions for both FPGA and main
rmware running in the
receiver.
Default
Returns all settings to the
factory defaults as shown in
the table below.
Menu Item Setting
Flexlist Cleared
Vol/Bal Centered
Mixer Mode Stereo
Limiter Pregain 0
HF Boost 0
Meter Mode Post-Mix
Backlight Always On
Battery Type Lithium
Earphone Type Stereo
Settings Unlock
Receiver Name M2Ra IEM Receiver
Frequency Depends on Locale:
NA/EU/JA 512.000
AU 525.000
EU/JA 537.600
AU 537.600
A1B1
B1C1
